Description
by
James a. Fucciani (Author)
Table of Contents: Standard Wall Pipe Data with ordinate spacing Decimal Equivalents of Fractions of an Inch 90Intersections LATERALS Template Layout 22 1/2Laterals 30Laterals 45Laterals 60Laterals Concentric Branch on Back of a 90Elbow Eccentric Branch on Back of a 90Elbow 90Eccentric Pipe Riser 5to 45Angle of Cut FABRICATED ELBOWS Template Layout 3-Piece 4-Piece 5-Piece 6-Piece FULL-SIZE WYES Template Layout 22 1/2Wye 30Wye 45Wye 60Wye MITER CUTS 1″ through 42″ 5 , 10 , 11 1/4 ,12 1/2 , 15 , 20 , 22 1/2 , 25 , 30 , 35 , 40 ,45 , 50 , 55 , 60 , 65 , 70 , 75 , 80 , 85
Number of Pages: 264Dimensions: 0.55 x 7.8 x 5.08 INPublication Date: July 08, 2016
